Cone Bottom Trailer (Triple)

Available in a 9,000-gallon size, triple Cone Bottom trailers feature hydraulic jacks, heavy-duty powder-coated steel frames and a built-in drainage system. These tanks include an industry-leading Ribbed Wall™ warranty and can be customized with your choice of pump and plumbing packages.

⚠️ Prices are estimates to show price range. See buying options below to get your price.

Product Code: CUSTTRPCONE7090
Get your local price here!
⚡ QUICK QUOTE
MSRP
Available Through Local Dealer


Add To Cart

MSRP
Complete this form and we will contact you with your best price!
  • SPECIFICATIONS

    Cone Bottom Trailer (Triple)

    Lights(Optional) DOT compliant clearance, stop, turn, tail
    Axle (s)6 x 3,500 lbs. Spindle or 7 x 3,500 lbs. Spindle
    Hitch Type20,000 lbs. Clevis
    Frame Construction6" x 2" Rectangle Tubing
    Pump2" Banjo® Centrifugal Poly, 195 GPM or 3" Banjo® Centrifugal Poly, 293 GPM
    MotorHonda® GX160 5.5HP or Honda® GX200 6.5 HP
    Electric Plug Light Option10 or 11 Pole RV Plug
    Tank TypePoly cone bottom storage tank
    Height(Raised - 158"/Lowered - 146")
    Dry Weight (lbs)4,070 lbs or 4,090 lbs
    Length29'
    Width100"
    Size (US Gallons)3 x 3,300
    Tires235/80 R16 10 PLY HWY Tire on Ag Wheel
    Hose Size2" or 3" Black Fertilizer
  • VIDEO

    Liquid Storage & Transport
